Seismic Shadow Zone: Basic Introduction

1min 48s Novice Spanish

How do P & S waves give evidence for a liquid outer core?

The seismic shadows are the effect of seismic waves striking the core-mantle boundary. P and S waves radiate spherically away from an earthquake's hypocenter (or focus) in all directions and return to the surface by many paths. S waves, however, don't reappear beyond an angular distance of ~103° (as they are stopped by the liquid) and P waves don't arrive between ~103° and 140° due to refraction at the mantle-core boundary.

CLOSED CAPTIONING: .srt file is included with the download. Use an appropriate media player to utilize captioning.

Keypoints:

  • The seismic shadow zone is the rea of the Earth's surface where seismographs cannot detect an earthquake after the waves have passed through the earth
  • P waves are refracted by the liquid outer core and are not detected between 104° and 140°
  • S waves cannot pass through the liquid outer core and are not detected beyond 104°
  • This information led scientists in the early 1900s to deduce a liquid outer core
